ENGINE发动机 |
|
|
Emission Standard排放标准 |
国三 |
|
Make /Model 制造商/型号 |
Kubota D1105发动机 |
|
Power /Rotation speed额定功率 |
18.4kw@2300rpm |
|
Number of cylinder气缸数 |
3 |
|
TRACK SYSTEM行走系统 |
|
|
Maximum Travel speed最大行驶速度 |
2.5/3.5km/h |
|
Width of track shoe履带宽度 |
230mm |
|
Number of track shoe per side履带板数量/每侧 |
38pcs |
|
Number of upper roller per side拖链轮数量/每侧 |
1 |
|
Number of bottom roller per side支重轮数量/每侧 |
3 |
|
PERFORMANCE PARAMETER性能参数 |
|
|
Standard Bucket capacity斗容 |
0.06m³ |
|
Swing speed回转速度 |
9rpm |
|
Maximum Grade ability最大爬坡度 |
35° |
|
Maximum Bucket digging force铲斗最大挖掘力 |
14KN |
|
Maximum Arm digging force斗杆最大挖掘力 |
10KN |
|
Hydraulic system pressure系统压力 |
18Mpa |
|
Machine weight整机重量 |
1800kg |
|
Fuel tank燃油箱容积 |
18L |
|
Hydraulic oil tank液压油箱容积 |
15L |
|
MACHINE SIZE尺寸 |
|
|
Overall dimension (L*W*H)外形尺寸 |
3865mm*1050mm*2270mm |
|
Height of cabin驾驶室高度 |
2270mm |
|
Track length on ground(Axle base)轴距 |
1230mm |
|
Track gauge轨距 |
820mm |
|
Minimum Ground clearance最小离地间隙 |
210mm |
|
Swing radius at tail尾部回转半径 |
1125mm |
|
WORKING RANGE工作范围 |
|
|
Maximum Digging height最大挖掘高度 |
3365mm |
|
Maximum Dumping height最大卸载高度 |
2385mm |
|
Maximum Digging depth最大挖掘深度 |
2050mm |
|
Maximum Vertical digging depth 最大垂直挖掘深度 |
1725mm |
|
Maximum Digging radius最大挖掘半径 |
3860mm |
|
Minimum swing radius最小回转半径 |
1720mm |
|
Maximum Lifting height of blade 推土铲最大提升高度 |
230mm |
|
Maximum Cutting depth of blade 推土铲最大下沉深度 |
275mm |
|
Boom swing angle(Left)动臂摆动角度 |
75° |
|
Boom swing angle(Right)动臂摆动角度 |
45° |
